☆ Mini size, widely used in wireless machine, self-service terminal.
☆ Read all mainstream 1D 2D barcodes in the market easily.
☆ Support USB barcode information transmission. ( languages customization)
☆ High brightness, dark environment scanning, low power consumption.
☆ Interface: USB, TTL.
☆ Support multiple systems and languages, secondary development.
| ▅ Lockers | ▅ Mobile coupons, tickets |
| ▅ Medical research | ▅ Mobile payment barcode scanning |
| ▅ Lottery machines | ▅ Self-service terminals |
| ▅ Queuing calling equipment | ▅ Self-service vending machines |
| ▅ Microcontroller development |
| Scan Type | CMOS |
| Light Source | White LED |
| CPU | 32-bit |
| Resolution | 640*480 |
| Resolution | 5mil code39 |
| Decoding speed | 25CM/S |
| Depth of field | 0mm-210mm |
| Scan Mode | Auto Sense |
| Scan angle | Roll±360°, Pitch±45°, Skew±32° |
| Print Contrast Signal | ≥25% |
| Ambient Light | 0-10000LUX |
| Symbologies | 1D：Code 39, codabar, Code 128/EAN128, Code 93,Code 11, Interleave 2 of 5, EAN.UCC Composite,Interleaved 2 of 5, MSI Code,Planet,Plessey Code,RSS,Standard 2 of 5, Telepen, UPC/EAN，etc. 2D: PDF417,QR CODE,Matrix 2 of 5,MicroPDF417,MaxiCode, AZTEC ，Codablock，TLC 39,DataMatrix,etc. |
| Weight | ≈18g |
| Dimension | 61mm L *65mm W * 27mm H |
| Communication Mode | USB |
| Power Supply | 280mA（working） |
| Cable（Optional） | USB Cable, used to connect the WD-1033 to a host device. |
| RS232 Cable, used to connect the WD-1033 to a host device, with USB supply cable. | |
| Test board（Optional） | With trigger button and buzzer, it has USB or RS232 output function. |
| Power Adaptor | Output: DC5V 1A, input: AC100~240V 50~60Hz（serial port optional). |
| Barcode | Precision | near | far |
| Code 39 | 0.1mm(5mil) | 10mm | 60mm |
| EAN-13 | 0.33mm(13.0mil) | 10mm | 110mm |
| QR Code | 20.0mil | 5mm | 80mm |
| WeChat payment code 6 inch screen | 5mm | 150mm | |
| Alipay payment code 6 inch screen | 30mm | 200mm |
Test Condition：T=25℃，Illumination=200LUX，PCS=0.9
