2D Wired Handhedl Barcode Scanner

Item No.: WD-679X
WD-679X is an economical 2D barcode scanner that uses a full set of patented technology developed by our company, with simple integration and stable performance.
Description
Description

WD-679X is an economical 2D barcode scanner that uses a full set of patented technology developed by our company, with simple integration and stable performance. Supports manual triggering and automatic continuous scan mode with fast and flexible speed. Using advanced CMOS image recognition technology, intelligent image recognition system, and patented illumination technology, it can read all kinds of 1D barcodes and 2D barcodes at high speed and all directions, achieving 4mil decoding capability. It can smoothly interpret reflective, wrinkle, blur, color bar code, can also be decoded normally under strong light and dark light environment, and has strong reading performance, providing users with an easy to use experience. Support Windows, MAC OS, Android, Linux system.
Characteristic
1.You can use it without installing a driver.
2.Wide voltage design avoids the occurrence of data transmission failure due to voltage fluctuations.
3. Multi-language support: support multi-language bar code information direct transmission.
4.The 32-bit main control chip is equipped with patented software, which can smoothly interpret reflective, wrinkled, fuzzy, and color bar codes. It can also be decoded normally under strong light and dark light.
5.Using full tantalum capacitor and anti-oxidation optical technology, it avoids the problem of sensitivity drop after using the traditional scanner for a period of time.

Net weight 160g (excluding wire)
Size 175mm L × 72mm W × 100mm H
Cable length 1.8m
Interface type USB port (free drive), USB virtual serial port (installation driver), TTL (free drive)
USB interface protocol Full Speed, USB 2.0
Material ABS+PC
Colour black
Performance parameter
Light source illumination: white LED    Aiming: green LED, wavelength 525nm
Image sensor 640×480 CMOS
CPU ARM32-bit
System start 4S
Resolution 1D: ≥ 4mil, 2D: ≥ 8.7mil @PCS90%
Depth of field 5 mil: 50~130mm, 13mil: 50~270mm
Scan mode Manual button scan, auto-sensing scan
Prompt mode LED indicator, buzzer
Reading angle roll±360°, Pitch: ±60° or greater, Yaw: ±70° or greater)
Field of view Horizontal 40°× Vertical 30°
Motion tolerance 2.3 m / s
Input power recommended DC5V input
Decoding average current 16mA
Print contrast 25% PCS
Ambient light resistance 70000LUX
Support barcode type 1D: Codabar, Code39, Code32, Interleaved 2 of 5 (ITF25), Industrial 2 of 5 Industrial 25 code, Matrix 2 of 5, Code93, Code11, Code128, Gs1-128, UPC-A, UPC-E, EAN/JAN-8, EAN/JAN-13, ISBN, ISSN, GS1 databar, GS1 databar limited, GS1 databar expanded
2D: PDF417, Micro PDF417, QR Code, Micro QR, Data Matrix, Aztec
Environmental parameters
Operating temperature -20°C to 55°C
Storage temperature -20°C to 60°C
Relative humidity 5% to 95% (non-condensing state)
IP grade IP67
Drop test 1.8 meters, 100 times
High and low temperature test 30 minutes for high Temp., 30 minutes for low Temp.,
High temperature 60° C
Low temperature -20 ° C
Transport shock test 10H@125RPM
