| Features: SIMPLE Distinct function area for fast switch and straightforward operation SAFE Supports real-time, storage and batch transmission WIRELESS Adopts mainstream wireless and storage technology, free from cables CAMPACT Cell phone size, easy to carry with comfortable feel |
|
| ※Radio Specifications： (optional Bluetooth or 433MHz) | |
| BLUETOOTH | |
| Frequency | ISM band，2.400～2.483MHz |
| Rate of Transmission | 2Mbps |
| Output Power | Bluetooth Class2，3dBm |
| Regulatory | Bluetooth 2.1 compliance |
| Transmission Coverage | 10M visibility range (Max.) |
| Antenna | Integrated PCB |
| 433MHz | |
| Frequency | ISM band，433MHz |
| modulation | GFSK |
| Rate of Transmission | 50Kbps |
| Output Power | 20dBm (max) |
| Transmission Coverage | 300M visibility range（Max.） |
| Antenna | Integrated PCB |
| ※Performance Characteristics： | |
| Light Source | 650nm Laser Diode |
| Scan Pattern | Single line |
| Scan Rate | 45±2 /sec |
| Scan Precision | 4mil |
| Scan Width | 20mm@window，220mm@200mm |
| Depth of Field | 0～500mm |
| Roll(Till) | 30° |
| Pitch | 65° |
| Skew(Yaw) | 55° |
| Resolution | 30% reflectance |
| Operating Mode | Continuous / itemized scanning |
| Error Rate | 1 million-to-one |
| Indicator | beeper，LCD |
| Decode Capability | EAN-8，EAN-13，UPC-A，UPC-E，Code 39，Code 93，Code 128，EAN128，Codaber，Industoal 2 of 5，Interleave 2 of 5，Matrix 2 of 5，MSI… |
| Interfaces supported | Mini USB receiver，optional RS232 or PS2 |
| ※Electrical Parameters： | |
| Receiver Voltage | DC5V |
| Receiver Current | 120mA |
| Battery | Rechargeable lithium ion battery (3.7V ,1700mAh) |
| Charging Indicator | LCD |
| Stockcount Working current | 150mA |
| Stockcount Standby Current | 50mA |
| Laser Safety | national classII regulatory |
| EMC | CE & FCC DOC compliance |
| ※Physical Characteristics： | |
| Memory | 4M |
| keypad | 17 keys |
| Stockcount Dimensions | 102mm×46mm×28mm |
| Material | ABS + silicon |
| ※User Environment： | |
| Operating Temperature | 0℃～45℃ |
| Storage Temperature | -20℃～60℃ |
| Humidity | 5%~95% (non-condensing) |
| Ambient Light Immunity | Max.5,000 Lux（fluorescent） |
