Features:
1. Compatible for 80mm and 58mm thermal paper roll
2. Wall mount function
3. Large storage (paper mode) and paper near end optional
4. High printing speed 250mm/s
5. Mainly adopt R angle and waist shape design; delicate and compact appearance
| Printing method | Direct thermal printing | |
| Effective printing width | 72mm or 48mm | |
| Resolution | 203dpi | |
| Printing speed | 250mm/s | |
| Printing density | 576 dots/line or 384 dots/line | |
| Character set | GB18030 (Simplified Chinese) | |
| Print font | ASCII Font A：12×24 | |
| ASCII Font B：9×17 | ||
| Chinese: 24×24 | ||
| Character per line | Font A-48 lines/Font B-64 lines/Chinese-24 lines | |
| Paper specification | Paper width | 79.5±0.5mm |
| Paper roll diameter | Φ80mm | |
| Paper loading | Easy paper loading | |
| Barcodes | Barcode type | UPCA/UPCE/EAN13/EAN8/CODE39/I25/CodeBar/CODE128/CODE93 |
| /CODE11/MSI/QRCORE/PDF417 | ||
| Reliability | Thermal printing head | 150km |
| Auto cutter | 1 million cuts | |
| Interface | USB+Serial+Lan | |
| Emulation | ESC/POS/OPOS | |
| Driver | WIN2003/WINXP/WIN7/WIN8/WIN10/LINUX/MAC | |
| Power supply | DC 24V,2.5A | |
| Cash drawer Control | DC 24V，1A | |
| Certificate | 3C、CE、FCCID 、BIS、ROHS | |
| weight | 1.07kg | |
| Dimension (LxWxH ) | 195×145×147mm | |
| Environment | temperature | working temperature: 0~45℃ |
| Storage：-10~60℃ | ||
| humidity | working temperature: 20-90% |
